Ertech AI806 4 Port 2 Up-link 60W Network Unmanaged PoE Switch

Specification

Network Interface
4 RJ4 5 ports with 10 / 100Mbps PoE function (Port 1~ Port 4 )
2 10 / 100Mbps non-POE function RJ45 ports (Port 5~ Port 6)

Transfer speed
100Mbps full duplex , 10 o r 100Mbps half duplex

Network protocol standard
IEEE 802.3 i , IEEE 802.3 u , IEEE 802.3 x , IEEE 802.3 a f / at _ _ _

Performance Specifications
Backplane Bandwidth: 1.2Gbps ( non- blocking )
Network Latency ( 10 0 to 100 M bps ): 20 microseconds max (using 64 – byte packet size)

Frame filtering and transfer rate:
10 M ports up to 14,800pp s
100 M ports up to 148,800pp s

LED indicator
Power Indicator
Llink/Act indicator
RESV: reserved
POE indicator

POE pin
1/2 (+), 3/6/(-);

Power support
The maximum output power of a single port is 30W .
Maximum power supply: 60 W ;

Physical Specifications
Dimensions ( LxWxH ) : 190mm x 131mm x 40mm
Weight : 1.5kg

Environmental Specifications
Operating temperature: 0°~40° C
Working humidity: 10% ~ 90% , non-condensing
Safety regulations :CE / ROHS / FCC
